Features

　　Extremely bright single color (up to 7000 lm)

　　Calibrated Blue ensuring color consistency

　　Adjustable color within Blue color ranges

　　Very low power consumption (max 139 W)

　　Choice of beam angles - 7.5°, 16°, 33°, 52°

　　Internal power and control

　　Super rugged IP65 housing

　　Choice of white, black or aluminum housing

　　0 – 100% intensity control

　　Tech Specs

　　PhysicalLength: 169 mm (6.8 in.) including cable glandWidth: 307 mm (12.1 in.)Height: 401 mm (16.8 in.)Weight: 7.6 kg (16.8 lbs.) including bracket

　　Dynamic EffectsDimming: 0 - 100% continuousColor fine-tuning: Continuously variable

　　Control and ProgrammingControl options: DMX, stand-alone, synchronized (master/slave)DMX channels: 1 or 3 depending on modeDMX address setting: PC with Martin MUM™ software and DABS1™ hardware interfaceStand-alone trigger options: Internal timer and/or ambient light levelStand-alone and master/slave programming: PC with Martin MUM™ software and DABS1™ hardware interface26-bit control (internal): Single color intensityProtocol: USITT DMX512-AReceiver: RS-485Firmware update: Serial upload via DMX link

　　OpticsLight source: Cree XP-E high power emittersMinimum LED lifetime: 50 000 hours (to >70% luminous output)*Very Narrow (no diffuser), Narrow, Medium and Wide beam angles available*Figure obtained under manufacturer's test conditions

　　ConstructionColor: Clear anodized, black or whiteHousing: Anodized aluminumMounting bracket: 8 mm (0.32 in.) anodized aluminumFront glass: 6 mm (0.24 in.) anti-reflection coatedProtection rating: IP65

　　InstallationOrientation: AnyMounting: Flat surface at any angle, pedestal or other suitable supportVertical aiming: 330°Minimum distance to illuminated surfaces: 0.1 m (0.33 ft.)

　　ConnectionsPower cable entry: IP68 cable glandPower connection: 1.8 m (5.9 ft.) cable tailData cable entry: IP68 cable glandData connection: 1.8 m (5.9 ft.) combined input + output cable tail

　　ElectricalAC power: 100-240 V nominal, 50/60 HzStandby power: 13 WPower supply unit: Integrated, auto-sensing multi-voltageMain fuse: 2.5 AT (slow blow)

　　Typical Power and Current100 V, 50 Hz: 139 W, 1.4 A, PF 0.990100 V, 60 Hz: 139 W, 1.4 A, PF 0.989110 V, 60 Hz: 137 W, 1.3 A, PF 0.988120 V, 60 Hz: 136 W, 1.2 A, PF 0.986208 V, 60 Hz: 133 W, 0.7 A, PF 0.932230 V, 50 Hz: 132 W, 0.7 A, PF 0.925240 V, 50 Hz: 131 W, 0.7 A, PF 0.886Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.

　　ThermalCooling: ConvectionMaximum ambient temperature (Ta max.): 45° C (113° F)Minimum ambient temperature (Ta min.): -30° C (-22° F), power must be maintained below 0° C (33° F)Maximum surface temperature, steady state, at 40° C ambient: 90° C (194° F)Total heat dissipation (calculated, +/- 10%): 480 BTU/hr.

　　ApprovalsEU safety: EN 60598-2-5 (EN 60598-1), IEC/EN 60825-1EU EMC: EN 55015, EN 55103-1, EN 55103-2, EN 61000-3-2, EN 61000-3-3US safety (US model): UL 1598Canadian safety (US model): CAN/CSA C.22.2 No. 250

　　Included ItemsAdjustable mounting yokeNarrow, Medium and Wide diffusersHard-wired 1.8 m (5.9 ft.) power and data in/out cable tails without connectorsUser manual

　　AccessoriesDiffuser, Exterior 400 Series, Narrow: P/N 41600122Diffuser, Exterior 400 Series, Medium: P/N 41600123Diffuser, Exterior 400 Series, Wide: P/N 41600124Diffuser, Exterior 400 Series, Narrow, Directional 15°x1°: P/N 41600156Diffuser, Exterior 400 Series, Medium, Directional 30°x3°: P/N 41600157Diffuser, Exterior 400 Series, Wide, Directional 60°x1°: P/N 41600158Diffuser, Exterior 400 Series, Wide, Directional 60°x10°: P/N 41600159Exterior 200 floor stand: P/N 91611305Safety eyebolt: P/N 916112393-pin male XLR connector, cable-type, IP65: P/N 916113063-pin female XLR connector, cable-type, IP65: P/N 91611307

　　Related ItemsMartin DABS1™ USB interface box incl. cables: P/N 90758090

　　Spare Parts2.5 AT main fuse: P/N 05020010

　　Ordering InformationExterior 430 Blue, EU Model, Aluminum: P/N 90545055
