Features

　　First real alternative to a 700/800 watt HID fixture

　　Flat field, crisp image, high contrast

　　Full feature set including CMY color mixing and 1:3 zoom

　　Very low weight and compact design

　　Super high-speed movements and effects

　　Consistent photometric performance via latest LED technology

　　Tech Specs

　　PhysicalLength: 452 mm (17.8 in.)Width (across yoke): 431 mm (17.0 in.)Height (head straight up): 642 mm (25.3 in.)Height (maximum): 648 mm (25.5 in.)Weight: 23.2 kg (51.1 lbs.)

　　Dynamic EffectsColor mixing: CMY, independently variable 0 - 100%Color wheel: 6 color filters plus openRotating gobo wheel: 6 interchangeable gobos plus open, wheel rotation, gobo rotation, indexing and shakeStatic gobo wheel: 10 gobos plus open, wheel indexing, rotation and shakeBeam effects: Rotating three-facet prismZoom: MotorizedFocus: Motorized, with zoom-focus trackingIris: 0 - 100%, pulse effectsShutter effect: Electronic, with variable speed regular and random strobeElectronic dimming: Four dimming curve optionsPan: 540°Tilt: 268°Pan and tilt speed: Adjustable via onboard control panel and DMX

　　Control and ProgrammingControl system: DMXRDM: ImplementedControl resolution: 8-bit, with 16-bit control of dimming, gobo indexing, zoom, focus, pan and tiltDMX channels: 19/27Setting and addressing: Control panel with backlit graphic displayDMX compliance: USITT DMX512-ARDM compliance: ANSI/ESTA E1.20Transceiver: RS-485Fixture software update: Direct using USB memory stick or via DMX link using Martin USB Duo™ DMX Interface Box

　　OpticsLight source: 475 W LED engineLED refresh rate: 3000 HzMinimum LED lifetime: 50 000 hours (to >70% luminous output)*Zoom range: 12° - 36° (1:3)Output: 12 700 lumens*Figure obtained under manufacturer´s test conditions

　　ConstructionColor: BlackHousing: High-impact flame-retardant thermoplasticProtection rating: IP20

　　InstallationMounting points: 4 pairs of quarter-turn locksLocation: Indoor use only, must be fastened to surface or structureOrientation: AnyMinimum distance to combustible materials: 0.2 mMinimum distance to illuminated surfaces: 2.0 m

　　ConnectionsAC power input: Neutrik PowerConDMX and RDM data in/out: 5-pin locking XLR

　　ElectricalAC power: 120-240 V nominal, 50/60 HzPower supply unit: Auto-ranging electronic switch modeMaximum total power consumption: 750 WTypical half-cycle RMS inrush current: 10.3 ATypical power consumption, all effects static, zero light output:Approx. 50 WMaximum total power consumption: 750 WTypical half-cycle RMS inrush current: 10.3 A

　　Typical Power and Current120 V, 60 Hz: 4.8 A, 576 W, PF 0.999208 V, 60 Hz: 2.8 A, 568 W, PF 0.991230 V, 50 Hz: 2.5 A, 565 W, PF 0.988240 V, 50 Hz: 2.4 A, 565 W, PF 0.988Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/- 10%.

　　ThermalCooling: Forced air (temperature-regulated, low noise, user-definable levels)Maximum ambient temperature (Ta max.): 40° CMinimum ambient temperature (Ta min.): 5° CTotal heat dissipation (calculated, +/- 10%): 2000 BTU/hr.

　　ApprovalsEU safety: EN 60598-2-17 (EN 60598-1), EN 62471EU EMC: EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547US safety (pending): UL 1573US EMC: FCC Part 15 Class ACanadian safety (pending): CSA C22.2 No. E598-2-17 (CSA E60598-1)Canadian EMC: ICES-003 Class AAustralia/NZ: C-TICK N4241

　　Included ItemsTwo omega brackets for rigging clamp attachment: P/N 91602001

　　Accessories3 m power cable, 12 AWG, SJT, with PowerCon NAC3FCA power input connector: P/N 11541503Neutrik PowerCon NAC3FCA power input connector, cable mount, blue: P/N 05342804Half-coupler clamp: P/N 91602005G-clamp: P/N 91602003Quick trigger clamp: P/N 91602007Flightcase for 2 x MAC Quantum™: P/N 91510210

　　Related ItemsMartin USB Duo™ DMX Interface Box: P/N 90703010Martin RDM 5.5 Splitter™: P/N 90758150

　　Ordering InformationMAC Quantum Profile™ in cardboard box: P/N 90240000MAC Quantum Profile™ in 2-unit flightcase: P/N 90240010
